Grundfos UNILIFT AP12.40.06.1
Product ID: 96001729
Request Price and Availability
Grundfos UNILIFT AP12.40.06.1
Grundfos UNILIFT AP12.40.06.1
| Liquid: | |
| Liquid temperature range: | 0 .. 55 °C |
| Selected liquid temperature: | 20 °C |
| Density: | 998.2 kg/m³ |
| Technical: | |
| Maximum flow: | 5 l/s |
| Type of impeller: | SEMI OPEN |
| Max. Particle: | 12 mm |
| Approvals: | CE,RCM,LGABG,EAC,TUVRHWID |
| Materials: | |
| Pump housing: | Stainless steel |
| EN 1.4301 | |
| AISI 304 | |
| Impeller: | Stainless steel |
| EN 1.4301 | |
| AISI 304 | |
| Cable union: | Brass |
| CW602N | |
| C35330 | |
| Installation: | |
| Range of ambient temperature: | 0 .. 55 °C |
| Type of connection: | Rp |
| Size of connection: | 1 1/2 inch |
| Place of installation: | Indoor/outdoor |
| Electrical data: | |
| Power input P1: | 0.9 kW |
| Motor type 1-phase: | PSC |
| Rated power - P2: | 0.6 kW |
| Mains frequency: | 50 Hz |
| Rated voltage: | 1 x 220-240 V |
| Rated current: | 4.4 A |
| Cos phi - power factor: | 0.99 |
| Rated speed: | 2785 rpm |
| Capacitor size - run: | 16 µF/400 V |
| Enclosure class (IEC 34-5): | IP68 |
| Insulation class (IEC 85): | F |
| Length of power cable: | 10 m |
| Type of cable plug: | AU |
| Others: | |
| Net weight: | 12 kg |
| Gross weight: | 12.5 kg |
| Environmental approvals: | WEEE |
Applications
- Domestic wastewater — With a series of optimised drainage pump systems, lifting stations and sump pumps, you can gain full control of domestic wastewater.
category
- Submersible wastewater pumpsGrundfos submersible wastewater pumps are designed as sealed units combining a pump and integrated motor that can operate below the surface of wastewater. Submersible wastewater pumps are perfect in permanent installations for efficient removal of wastewater from a property whether from washing machines, sinks and showers or drainage from the garden.
