Grundfos SQE 2-35 N
Product ID: 96160445
Request Price and Availability
Grundfos SQE 2-35 N
Grundfos SQE 2-35 N
3" multi-stage, submersible pump designed for domestic water supply, liquid transfer in tanks, irrigation and environmental applications. The pump has "floating" impellers, each with its own tungsten carbide/ceramic bearing.
The pump features soft starting and protection against dry-running, upthrust, overvoltage, undervoltage, overload and overtemperature.
The motor is a single-phase motor of the permanent magnet rotor type ensuring optimum efficiency within a wide load range. The motor is fitted with a replaceable end cover with socket.
| Liquid: | |
| Pumped liquid: | Water |
| Liquid temperature range: | 0 .. 35 °C |
| Selected liquid temperature: | 20 °C |
| Density: | 998.2 kg/m³ |
| Technical: | |
| Pump speed on which pump data are based: | 10700 rpm |
| Rated flow: | 2 m³/h |
| Rated head: | 35 m |
| Approvals: | CE,PCBC,RCM,EAC,CN Rohs Exempt,Morocco,UKCA,SEPRO |
| Curve tolerance: | ISO9906:2012 3B |
| Materials: | |
| Pump: | Stainless steel |
| EN 1.4401 | |
| AISI 316 | |
| Impeller: | Composite |
| ZYTEL 70G30 HSLR PA6.6-GF30 | |
| Motor: | Stainless steel |
| DIN W.-Nr. 1.4401 | |
| AISI 316 | |
| Installation: | |
| Maximum operating pressure: | 15 bar |
| Pump outlet: | RP1 1/4 |
| Minimum borehole diameter: | 76 mm |
| Electrical data: | |
| Motor type: | MSE3-N |
| Power input - P1: | 1 kW |
| Rated power - P2: | 0.7 kW |
| Power (P2) required by pump: | 0.47 kW |
| Mains frequency: | 50 Hz |
| Rated voltage: | 1 x 200-240 V |
| Rated current: | 5.3 A |
| Power factor: | 1.00 |
| Rated speed: | 10700 rpm |
| Start. method: | direct-on-line |
| Enclosure class (IEC 34-5): | IP68 |
| Insulation class (IEC 85): | F |
| Length of cable: | 1.5 m |
| Motor No: | 96195294 |
| Others: | |
| Net weight: | 4.7 kg |
| Gross weight: | 5.4 kg |
| Shipping volume: | 0.009 m³ |
Applications
- Domestic ground water intake — Groundwater is essential for water supply. Providing a reliable, fresh supply of water for all homeowners is equally essential, particularly for those whose water source is a private groundwater well.
- Domestic water pressure boosting — Low or varying water pressure in the home? A water pressure pump solves the very common problems of low-pressure showers and trickling taps that reduce comfort in one- or two-family homes.
- Ground water intake — You require a cost-effective, reliable and energy-optimised submersible pumping solution for borehole installations. Our pumps and pump systems are optimised for the highest performance and reliability for groundwater installations.
category
- Submersible groundwater pumpsGrundfos submersible pumps represent advanced hydraulic design and offer high efficiency, high resistance to sand and other abrasives, motor burnout protection and easy maintenance. Made entirely of corrosion-resistant stainless steel, Grundfos submersible pumps are ideal for applications including groundwater supply, irrigation, groundwater lowering and pressure boosting.
