Grundfos SP 3A-6 NE
Product ID: 10220006
Request Price and Availability
Grundfos SP 3A-6 NE
Grundfos SP 3A-6 NE
Multi-stage submersible pump for raw water supply,groundwater lowering and pressure boosting. The pump is suitable for pumping clean, thin, non-agressive liquids without solid particles or fibres.
| Liquid: | |
| Pumped liquid: | Water |
| Liquid temperature range: | -15 .. 90 °C |
| Selected liquid temperature: | 20 °C |
| Density: | 998.2 kg/m³ |
| Technical: | |
| Pump speed on which pump data are based: | 2900 rpm |
| Rated flow: | 3 m³/h |
| Rated head: | 28 m |
| Approvals: | CE,EAC,UKCA,SEPRO,MOROCCO |
| Curve tolerance: | ISO9906:2012 3B |
| Return valve: | NO |
| Specification for shaft end: | CYLINDRICAL |
| Materials: | |
| Pump: | Stainless steel |
| EN 1.4401 | |
| AISI 316 | |
| Impeller: | Stainless steel |
| EN 1.4401 | |
| AISI 316 | |
| Installation: | |
| Maximum operating pressure: | 15 bar |
| Maximum outlet pressure: | 3.8 bar |
| Type of connection: | Rp |
| Size of connection: | 1 1/4 inch |
| Minimum borehole diameter: | 105 mm |
| Electrical data: | |
| Motor flange design: | Grundfos |
| Power (P2) required by pump: | 0.37 kW |
| Others: | |
| Minimum efficiency index, MEI ≥: | 0.70 |
| Net weight: | 4.1 kg |
| Gross weight: | 5.3 kg |
| Shipping volume: | 0.011 m³ |
Spare Parts
| Part Number | Product Name |
|---|---|
| 96440231 | Kit, Wear parts |
Applications
- Ground water intake — You require a cost-effective, reliable and energy-optimised submersible pumping solution for borehole installations. Our pumps and pump systems are optimised for the highest performance and reliability for groundwater installations.
