Grundfos CU 301 (96436753)
Product ID: 96436753
Request Price and Availability
Grundfos CU 301 (96436753)
Grundfos CU 301 (96436753)
The Grundfos CU 301 is a control and communication unit developed for the SQE submersible pumps for applications where a constant pressure is required.
The CU 301 provide full control of the SQE pumps and enables the system to maintain a constant pressure within the maximum pump performance in spite of a varying water consumption. The pressure is registered by the pressure sensor and transmitted to the CU 301. The CU 301 adjusts the pump performance accordingly.
The CU 301 control un
| Specification | Value |
|---|---|
| External sensors: | Reception of data from external sensors and control according to the data received from the pressure sensor. |
| Electrical data: | |
| Mains frequency: | 50 / 60 Hz |
| Rated voltage: | 1 x 100-240 V |
| Others: | |
| Danish VVS No.: | 388449701 |
| Norwegian NRF no.: | 9041361 |
Applications
- Domestic ground water intake — Groundwater is essential for water supply. Providing a reliable, fresh supply of water for all homeowners is equally essential, particularly for those whose water source is a private groundwater well.
- Ground water intake — You require a cost-effective, reliable and energy-optimised submersible pumping solution for borehole installations. Our pumps and pump systems are optimised for the highest performance and reliability for groundwater installations.
