Grundfos CMB-SP 3-56 I-C-A-A-C-A
Product ID: 98507630
Request Price and Availability
Grundfos CMB-SP 3-56 I-C-A-A-C-A
Grundfos CMB-SP 3-56 I-C-A-A-C-A
| Controls: | |
| Type of connector: | Type I (AS/NZS 3112) |
| Liquid: | |
| Pumped liquid: | Water |
| Liquid temperature range: | 0 .. 40 °C |
| Selected liquid temperature: | 20 °C |
| Density: | 998.2 kg/m³ |
| Technical: | |
| Pump speed on which pump data are based: | 2900 rpm |
| Rated flow: | 3 m³/h |
| Rated head: | 42.1 m |
| Primary shaft seal: | AVBE |
| Code for shaft seal: | AVBE |
| Approvals: | RCM |
| Curve tolerance: | ISO9906:2012 3B |
| Return valve: | YES |
| Self-priming: | 4 m |
| Start pressure: | PM2 |
| Materials: | |
| Pump housing: | Stainless steel |
| EN 1.4301 | |
| AISI 304 | |
| Impeller: | Stainless steel |
| EN 1.4301 | |
| AISI 304 | |
| Installation: | |
| Maximum ambient temperature: | 50 °C |
| Maximum operating pressure: | 10 bar |
| Pipe connection standard: | ISO 228-1 |
| Type of inlet connection: | Rp |
| Type of outlet connection: | G |
| Size of inlet connection: | 1 |
| Size of outlet connection: | 1 |
| Pressure rating for connection: | PN 10 |
| Electrical data: | |
| Rated power - P2: | 0.67 kW |
| Mains frequency: | 50 Hz |
| Rated voltage: | 1 x 220-240 V |
| Maximum current consumption: | 4.4-4.0 A |
| Rated speed: | 2720-2800 rpm |
| Enclosure class (IEC 34-5): | IP55 |
| Insulation class (IEC 85): | F |
| Built-in motor protection: | TP 211 |
| Length of cable: | 1.5 m |
| Power plug: | Australian plug |
| Tank: | |
| Tank volume: | NONE l |
| Others: | |
| Net weight: | 17.6 kg |
| Gross weight: | 22.8 kg |
| Environmental approvals: | WEEE |
Applications
- Commercial water pressure boosting — Ensuring optimal water pressure can be a challenge. However, you can overcome that challenge by means of an efficient and reliable booster system, which communicates with the entire system, and thus reducing life-cycle costs.
- Domestic water pressure boosting — Low or varying water pressure in the home? A water pressure pump solves the very common problems of low-pressure showers and trickling taps that reduce comfort in one- or two-family homes.
