Grundfos SQF 5A-3 N
Product ID: 95027339
Request Price and Availability
Grundfos SQF 5A-3 N
Grundfos SQF 5A-3 N
| Specification | Value | |
|---|---|---|
| Liquid: | ||
| Pumped liquid: | Water | |
| Maximum liquid temperature: | 40 °C | |
| Liquid temperature during operation: | 20 °C | |
| Density: | 998.2 kg/m³ | |
| Technical: | ||
| Approvals on motor nameplate: | CE,RCM,EAC | |
| Materials: | ||
| Pump: | Stainless steel | |
| DIN W.-Nr. 1.4401 | ||
| AISI 316 | ||
| Impeller: | Stainless steel | |
| DIN W.-Nr. 1.4401 | ||
| AISI 316 | ||
| Installation: | ||
| Maximum ambient pressure: | 15 bar | |
| Pump outlet: | Rp 1 1/2 | |
| Minimum borehole diameter: | 102 mm | |
| Electrical data: | ||
| Motor type: | MSF3N | |
| Power input - P1: | 1.4 kW | |
| Rated voltage ac: | 1 x 90-240 V | |
| Rated voltage dc: | 30-300 V | |
| Rated current: | 8.4 A | |
| Power factor: | 1,0 | |
| Rated speed: | 500-3600 rpm | |
| Start. method: | direct-on-line | |
| Enclosure class (IEC 34-5): | IP68 | |
| Insulation class (IEC 85): | F | |
| Length of cable: | 2 m | |
| Udc: | 300 V | |
| 30 V | ||
| Others: | ||
| Minimum efficiency index, MEI �?�: | 0.56 | |
| Net weight: | 9.3 kg | |
| Gross weight: | 10.8 kg | |
| Shipping volume: | 0.028 m³ | |
Applications
- Community water supply — Reliable, sustainable and low-risk community water systems from source to tap, including water management and revenue collection systems, for low-income remote or informal urban settlement areas in developing countries.
- Solar water solutions — Grundfos supplies solar-powered water pumps and complete solar water solutions that deliver unmatched flexibility for reliable water supply with no ongoing energy costs.
category
- Solar water pumping systemsx
- Submersible groundwater pumpsGrundfos submersible pumps represent advanced hydraulic design and offer high efficiency, high resistance to sand and other abrasives, motor burnout protection and easy maintenance. Made entirely of corrosion-resistant stainless steel, Grundfos submersible pumps are ideal for applications including groundwater supply, irrigation, groundwater lowering and pressure boosting.
