Typical Applications |
- Steam service in power plants
- Hot condensates
|
Technical Data |
| BODY MATERIAL: | 316 stainless steel, carbon steel, Hastelloy® C-276, and Monel® |
| MAXIMUM OPERATING PRESSURE: | 414 Bar @ 21° C |
| PROOF PRESSURE SAFETY FACTOR: | 2:1 |
| BURST PRESSURE: | 4:1 |
| OPERATING TEMPERATURE RANGE: | -75° C to + 538° C @ 120 bar max. |
| ORIFICE: | 4.3 mm
6.4 mm
7.9 mm
11.1 mm |
| Cv FACTOR: | 0.47, 1.09, and 1.20 | |
Features & Benefits |
- Meets ANSI 900# specifications
- Grafoil® packing below threads isolates threads from media.
- Non-rotating 316 stainless steel stem tip prevents galling
- High pressure / high temperature use
- All standard components are 316 stainless steel
- Standard 316 stainless steel cast handle
- Fractional end connections available up to 1”; metric end connections up to 25 mm
- Gyrolok®, female NPT, NPS-, or tube socket weld end connections
- Bubble-tight leak testing at both seat and packing
| |
