Typical Applications |
- Hydraulic systems
- High temperature service to +316° C
- Gas sampling
- Test stands
|
Technical Data |
| BODY: | 316 stainless steel, carbon steel, brass |
| MAXIMUM OPERATING PRESSURE: | 414 Bar @ 21° C |
| OPERATING TEMPERATURE RANGE: | Stainless steel:
414 Bar @ 21° C
Carbon steel:
345 Bar @ 21° C
Brass:
207 Bar @ 21° C |
| ORIFICE: | 4.8 mm
6.4 mm
8.0 mm |
| Cv FACTOR: | 0.40 to 1.20 | |
Features & Benefits |
| Safety |
- Back seating provides added sealing protection
- Lock pin prevents accidental bonnet disengagement
|
| High pressure capability |
- 316 stainless steel valve maximum working pressure is 414 Bar
|
| Extended temperature range |
- Choice of Dyna-Pak® packing or high temperature Graph-Lock® packing
|
| Versatile |
| |
| Reliability |
- All valves are tested for bubble-tight leakage at both seat and packing
|
| Panel mounting |
- Panel mounting is standard on all models
| |
