Typical Applications |
- Cylinder valves
- Panel board instrumentation
- Pressure gauge valves
- Sampling systems
- Research laboratories
- Oxygen service
- Corrosive or high pressure service
|
Technical Data |
| BODY: | 316 stainless steel, Monel® |
| MAXIMUM OPERATING PRESSURE: | 414 Bar @ 21° C |
| OPERATING TEMPERATURE RANGE: | Metal stem tip:
-54° to +232° C
PCTFE stem:
-29° to +121° C |
| ORIFICE: | 4.8 mm |
| Cv FACTOR: | 0.31 | |
Features & Benefits |
| Safety |
- Lock nut secures packing nut to prohibit accidental removal
|
| Long cycle life |
| |
| Helps eliminate fugitive emissions |
- Dyna-Pak® packing provides a leak-tight seal with low operating torque
|
| Reliability |
- All valves are tested for bubble-tight leakage at both seat and packing
|
| Installation variety |
- Broad selection of male NPT, female NPT, and HOKE Gyrolok® fractional or metric tube fitting connections
|
| Panel mounting |
- Panel mounting is standard on all models
| |
